flexible joint

flexible joint

external pipe diameterDw(mm)nominal diameterDN(mm)Allowedaxial loading(kgf)Expansionamount(mm)allowed corner(ø)minimumlength(mm)maximumlength(mm)installationlength(mm)fitted boltd x L(mm)898026801017.9080859016 x 5010810035501015.06909510016 x 5013312546201013.05909510016 x 6015915055301012.099......

Send Inquiry

Product Description

external pipe diameter
Dw
(mm)
nominal diameter
DN
(mm)
Allowed
axial loading
(kgf)
Expansion
amount
(mm)
allowed
corner
(ø)
minimum
length
(mm)
maximum
length
(mm)
installation
length
(mm)
fitted bolt
d x L
(mm)
89
80
2680
10
17.90
80
85
90
16 x 50
108
100
3550
10
15.06
90
95
100
16 x 50
133
125
4620
10
13.05
90
95
100
16 x 60
159
150
5530
10
12.09
90
95
100
16 x 60
194
175
7370
10
10.51
90
95
100
16 x 60
219
200
9370
10
9.33
100
105
110
16 x 70
245
225
11750
10
8.36
100
105
110
16 x70
273
250
14620
10
7.51
100
105
110
18 x 70
325
300
20680
12
6.32
100
106
112
18 x 70
377
350
27875
12
5.45
100
106
112
18 x 80
426
400
35600
12
4.80
100
106
112
18 x 80
480
450
45180
12
4.28
100
106
112
18 x 80
530
500
55120
12
3.88
100
106
112
18 x 80
630
600
65900
20
3.27
120
130
140
20 x90
720
700
70170
20
2.86
120
130
140
20 x90
820
800
84400
20
2.51
120
130
140
20 x 90
920
900
106200
20
2.24
130
140
150
18 x 90
1020
1000
116870
20
2.02
130
140
150
18 x 90
1220
1200
130600
20
1.69
130
140
150
18 x 90
1420
1400
146200
20
1.45
140
150
160
20 x 90
1620
1600
158300
20
1.27
140
150
160
20 x 90
1820
1800
166000
20
1.13
140
150
160
20 x 90
2020
2000
179000
25
1.01
145
165
170
20 x 90
2220
2200
187000
25
1.01
145
165
170
20 x 90
2420
2400
196000
25
1.01
145
165
170
20 x 90
2620
2600
206000
25
1.01
145
165
170
20 x 90
2830
2800
253300
25
1.01
145
165
170
20 x 90
3020
3000
260100
25
1.01
145
165
170
20 x 90
3220
3200
286900
25
1.01
145
165
170
20 x 90
